Use the display controls to show or hide isolated nodes, manually hidden nodes, node labels, and relationship arrowheads. These controls help you simplify a busy map or bring more detail into view.

1. Find the display controls

  1. Log in to PARTNER CPRM and open your ecosystem.
  2. Under Explore, open Ecosystem to map ecosystem data, or open Networks and select the network you want to analyze.
  3. Select the Network Map tab.
  4. Look for the vertical stack of buttons in the upper-left corner of the map, beside the Search Members field. Hover over a button to see its name.

The main controls appear in this order:

ButtonWhat it does
Isolated NodesShows or hides nodes with no connections in the current map.
Hidden NodesShows or hides nodes you have manually marked as hidden.
Node LabelsCycles between short names, full names, and no labels.
ArrowheadsShows or hides arrowheads that indicate the direction of relationships.

Some capture types may also show a Date Slider button in this group.


2. Choose how node names are displayed

Node Labels is a three-state button. Click it repeatedly to cycle through:

Short name → Full name → Off → Short name

StateWhat you see
Short nameThe member's Map Label, such as HF. The button displays a 1 in this state.
Full nameThe member's full Member Name, such as HealthFirst.
OffNo names appear on the nodes. The nodes and relationship lines remain visible.

Use short names for a compact overview, full names when viewers need to identify members, and Off when labels make a dense map difficult to read. Changing the label state does not change the member names or map labels stored in your member library.

Full-name labels:


Labels turned off:


3. Show or hide manually hidden nodes

A manually hidden node is different from an isolated node. It may have relationships, but you have chosen to hide it from the map.

To hide an individual node, click it to open its information popup, then click the Hide Node eye icon.

Use the Hidden Nodes button to review these nodes:

  1. Turn Hidden Nodes on to reveal nodes marked as hidden.
  2. Turn it off to hide those nodes again. Their hidden status is retained while you switch between the two views.

To remove a node's hidden status, turn Hidden Nodes on, click the revealed node, and choose Show Node in its popup. You can then turn Hidden Nodes off; that node will remain visible if the other display settings and filters allow it.


This control does not clear your attribute or relationship filters. If a member is still missing, check those filters and the Isolated Nodes setting as well.

4. Adjust isolated nodes and arrowheads

Click Isolated Nodes to include or exclude nodes without connections in the current map. Showing them can help identify members who are not connected; hiding them can make the connected portion of your network easier to explore.

Click Arrowheads to show or hide relationship direction indicators. Hiding arrowheads reduces visual detail; it does not remove the relationships or change their direction in your data.

If toggling Isolated Nodes or Hidden Nodes has no visible effect, your current map may not contain any nodes in that category.

For help with your network map, contact support@visiblenetworklabs.com.
